Help with Nightfox Nova Night vision binoculars

Help with Nightfox Nova Night vision Binoculars

Download PDF manual

FIRMWARE UPDATES

Download firmware version 20260605-1
The Nova's firmware can be updated to improve performance and fix some software bugs.

Our recommended stable firmware version is 20260605-1. You can find your current firmware version by going to the device Settings and choosing 'Version'.

Do not use this firmware on any other device: you will cause irreparable damage by doing so.

We have updated the Nova firmware in response to your feedback. The table below outlines the key improvements of each update.

Version Changes
1205-11:52 The original Nova firmware
20260605-1 Fixes a video recording file issue. Nova no longer stops recording when HDMI cable is unplugged.


How to update your firmware

1. Plug your Nova into your PC via USB cable.
Nightfox Nova on a desk plugged into a laptop
2. Download the firmware .BIN file by clicking on the 'Download firmware version 20260605-1' button (above and below these instructions). The file 'Rom_Code_NVB300_SVN27985_2026-6-5.bin' will save to your Downloads folder.
Screenshot showing downloaded BIN file
3. Copy the BIN file and paste it onto the Nova's memory card. Don't paste it into a subfolder. Make sure there is only one BIN file on the memory card.
Screenshot showing BIN file uploaded to memory card
4. Unplug the Nova from the USB cable. The Nova will turn off. Turn it back on.
Powering on the Nightfox Nova
5. Navigate to the Settings menu by long pressing the M button to reach Playback Mode, then long press M again to reach Settings.
Changing mode on the Nightfox Nova
6. Scroll down to 'Version' and click OK.
Nova settings menu
7. Scroll down to 'Firmware Update' and click OK.
Nova firmware update display
8. A red 'Firmware upgrading' screen will appear. After ten seconds, the Nova will turn off.
Updating firmware screen on Nightfox Nova
9. Turn the Nova back on. Your firmware is now updated.
Nightfox Nova with illuminated buttons ready for use

Download firmware version 20260605-1

Getting Started with Nightfox Nova

1. Charge Before First Use

Nova charges via USB-C, just like a phone or tablet.

Plug the supplied USB-C cable into a USB power source.

Connect the angled end to Nova.

Full charge time is approximately 5 hours.

Tip: Even if Nova is not used regularly, charge it at least once every three months to maintain battery health.


2. Check the Memory Card

Nova comes with a pre-installed 64GB memory card.

If you need to remove or reseat the card:

  • Power the device off.
  • Open the USB cover.
  • Push the memory card in gently to release it.
  • Reinsert with the gold pins facing down, then push until it clicks into place.

Tip: If “Memory Full” appears on the screen, transfer your files to a computer or external device and delete them from the card before continuing.


3. Power On

Long press the Power button to turn Nova on.

Nova automatically starts in Video Mode.

Look through the viewfinder and adjust focus using the lens focus wheel. Refocus at each use for the sharpest image.


4. Day vs Night Setup

For Daytime Use

Infrared (IR) should be turned off in daylight.

  • Press IR↓ until IR:OFF is displayed.
  • The image will appear in colour when IR is off.

For Night Use

  • Press IR↑ to increase IR strength from Auto to levels 0–5.
  • Use higher IR levels in darker conditions.
  • IR:0 or Auto may be sufficient where there is some ambient light.

5. Adjust Quick Settings

Press OK in Video Mode to access Quick Settings.

You can adjust:

  • IR level – controls infrared brightness
  • Sensitivity – similar to ISO exposure (increase in darker environments)
  • Backlight – adjusts LCD screen brightness

For fast-moving wildlife, consider using 60FPS in Settings for smoother motion.
